AGV/AMR, composed of hydraulic lifting system, differential drive system, steering wheel drive system, PLC control system, guidance system, communication system, alarm system, operating system, power system, etc., can solve the material handling problems in intelligent factories and other special environments, and is widely used in automobiles, electric power, chemical, steel, military, nuclear power and other industries. Remarkable offers 1-20 tons of non-standard customized solutions.
| Model | 2t | 20t | 50t | 100t | 150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Heigth(H) | 450 | 550 | 650 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 2.2 | 5 | 10 | 15 | |
| Running time When Full Load | 4.32 | 4 | 3.3 | 3.2 | 2.9 | |
| Running Distance for Once Charge(KM) | 6.5 | 4.8 | 4 | 3.8 | 3.2 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
Hybrid Navigation McNamm Wheel AGV
Automatic mold trackless transfer cart
Automatic wheel set battery transfer carts
10 tons integrated manufacturing system AGV transfer cart
AGV transfer vehicle battery transfer cart
Automated Transfer Cart Agv Handling Robot
3 ton Self propelled electric transfer trolley Magnetic Navigation AGV
Aerospace equipment
Nuclear Power
Shipyard
Power and Electrical
Automotive manufacturing
Buildings, high-speed railway bridges
Equipment manufacturing
Steel & Foundry
Chemical Industry
Oil & Natural Gas
New energy
Research institutions
Home appliance communication industry
Animal husbandry
At the very beginning of formulating a solution, our engineers will predict the faults that might occur during the equipment utilization relying on their rich experience, and avoid quality risks in advance.
Before getting inside the warehouse, all steel plates must be pretreated and testified to be qualified.
There is quality inspection in every process. The previous process can be allowed to enter the next one only if it is qualified. The whole process inspection records must be well preserved.
Before delivery, all the transfer carts/trolleys must undergo performance test, including load forward and backward, obstacle avoidance, omnidirectional mobile, slope climbing, lifting, wireless remote control, etc.
